Cov khoom paramenters
|
Qauv |
SC-R100 |
SC-R200 |
||
|
Series kev sib txuas |
15S |
15S |
||
|
Roj teeb Zog |
PEB 5.12 kWh |
10.24 KWh |
||
|
Nominal Peev Xwm |
100 Aw |
200 Aw |
||
|
Nominal voltage |
48V |
48V |
||
|
Charge Voltage |
58.2V |
58.2V |
||
|
Tshem Tawm Tawm Tawm Voltage |
42V |
42V |
||
|
Standard Charging Tam sim no |
20A |
20A |
||
|
Max.Continuous Charging Current |
100A |
100A |
||
|
Max Continuous Discharge Current |
100A |
100A |
||
|
Lub neej voj voog |
Ntau dua lossis sib npaug rau 6000 zaug @ 80% DOD, 25 degree |
Ntau dua lossis sib npaug rau 6000 zaug @ 80% DOD, 25 degree |
||
|
Kev sib txuas lus raws tu qauv |
RS485/CAN |
RS485/CAN |
||
|
Charge Temperature Range |
0 ~ 60 degree |
0 ~ 60 degree |
||
|
Tshem tawm qhov kub thiab txias |
-10 degree ~ 65 degree |
-10 degree ~ 65 degree |
||
|
Loj (LxWxH) |
530 × 493 × 175 hli |
515 × 493 × 350mm |
||
|
Net nyhav |
45 KG |
90 KG |
||
|
Pob Loj (L × W × H) |
530 × 540 × 260mm |
530 × 540 × 570 hli |
||
|
Qhov hnyav tag nrho |
55 KG |
110 KG |
||
